Installation of Submersible Mixers without Drainage

In order to ensure safety and not affect production, the installation system is a non-draining customized installation system, which does not need to be installed at the bottom of the pool to avoid installation risks.

Material requirements: The installation system is made of 304 stainless steel, in order to ensure the stability of the structure, the outer frame of the installation system is channel steel, and the raw material material certificate needs to be provided.

Structural requirements: The installation system requires a compact structure, due to the huge underwater thrust of the submersible mixer, the installation system cannot work in the air, and must be a complete structure from the bottom of the pool to the top.

Anti-falling design: The installation system works in the water all year round, and it is inevitable that pig manure residue and other substances will be adhered to the lifting rail of the submersible mixer to hinder the lifting of the submersible mixer.

The installation system must be able to manually adjust the angle to ensure that the mixing effect is free of dead angles.

Lifting device: 4KW6 below the submersible mixer is lifted by hand-cranked winch wire rope, the wire rope is required to be made of 304 stainless steel, and the hand-cranked winch can withstand 0.5 tons of heavy loads. The submersible mixer above the 4kw 12 pole is lifted by a chain hoist, and the hand zipper and guide chain are required to be made of 304 stainless steel, and the chain block can withstand 1 ton of heavy load.

The installation system adopts the form of no fixed pool in the pool and fixed at the top of the pool to ensure the smooth operation of the mixer, no welding cracking, no vibration in the operation of the mixer, and a rubber pad at the bottom of the mixer to absorb shock.

The installation system is required to be easy to install, tailored according to the depth of the user pool, the installation system requires portability, pool A and pool B are the same depth, the installation system is in pool A, pool B can be transplanted to pool B when needed.

Technical maturity: It is required to provide more than five company units that use the installation system to ensure the technical maturity of the installation system.

Appearance: The installation system requires smooth grinding and no welding slag, and the appearance is beautiful and tidy.

The installation system requires woven packaging to ensure the integrity of the appearance.

The installation system must adopt the structural principle of heavy and light on the bottom, the thrust of the bottom of the submersible mixer is huge, and the stability of the structure under the pool is the foundation. For further details about our installation system, please visit our website or contact us at LL Water Treatment or Contact Us.
