Product Description
Made of premium ABS engineering plastic. This professional integral casting filter plate formwork is specially used for installing adjustable filter heads and completing one-piece pouring of filter tank concrete plates, fundamentally solving the problems of traditional split filter plates such as joint leakage, uneven air and water distribution.
Adopting high-quality ABS engineering plastic flute plate structure, the ABS Filter Plate has excellent structural strength, which can ensure no deformation during concrete pouring. The surface is smooth and flat, free of cracks, shrinkage marks, bubbles and other defects, greatly reducing the risk of pouring rework, extending the service life of the filter plate, and reducing the long-term operation cost for water treatment plants and engineering contractors.
The convex platform of the formwork is designed with round holes with neck sleeves, which are used to fix the pre-embedded seat of the adjustable filter head. The filter head can be adjusted horizontally with high precision, which can adjust the air distribution of the whole filter tank to the same level, making the air and water distribution more uniform, improving the filtration efficiency of the filter tank, and reducing the energy consumption of backwashing.
The ABS Filter Plate greatly simplifies the construction procedure of the integral pouring filter plate, improves the degree of mechanized construction, shortens the construction period by more than 30%, and reduces the comprehensive project cost. It is the ideal choice for large-scale filter tank construction and renovation projects.
Parameter | Standard Specification | Customization Support |
Base Material | Premium ABS Engineering Plastic | Modified material for special working conditions |
Standard Single Plate Size | 500×500mm, 1000×500mm | Customized per filter tank size |
Effective Thickness | 140-200mm | Customized thickness range |
Filter Head Hole Spacing | 150×150mm | Customized hole spacing and layout |
Hole Diameter | Standard 30mm | Matched with filter head size |
Flatness Tolerance | ≤0.5mm/m | Higher precision customization available |
Applicable Temperature | 0-60℃ | High temperature resistant modification |
Pre-Installation Leveling & Positioning
Clean the filter tank bottom, set the elevation reference line, and complete the leveling of the supporting keel according to the design requirements.
Formwork Splicing & Fixing
Splice the ABS Filter Plate according to the layout drawing, fix the spliced formwork tightly, and ensure the overall flatness meets the tolerance requirements.
Pre-Embedded Seat Installation
Install the adjustable filter head pre-embedded seat into the reserved hole with neck sleeve, and fix it firmly to prevent displacement during pouring.
Concrete Pouring & Curing
Bind the reinforcement mesh, pour the reinforced concrete uniformly, and carry out standard curing to ensure the integral strength of the filter plate.
Filter Head Leveling & Acceptance
Install the adjustable filter heads after curing, complete the horizontal leveling of all filter heads, and conduct water distribution and air distribution uniformity tests.
Municipal drinking water treatment plant rapid filter tanks and air-water backwash filter tanks
Sewage treatment plant advanced treatment denitrification filter tanks and deep bed filter tanks
Industrial water purification and softened water treatment filter systems
Old filter tank renovation and upgrading projects
Water reclamation and reuse advanced filtration systems
Swimming pool and landscape water circulation filtration projects
Lanling is a leading professional supplier of water treatment filter tank supporting products, with more than 20 years of R&D and manufacturing experience, serving global customers including water plant operators, municipal engineering contractors, environmental protection engineering companies and water treatment equipment integrators. Our ABS Filter Plate is manufactured with high-precision molds, strictly tested for quality before delivery, supports full customization of size, hole spacing, thickness and material, and provides full on-site installation technical guidance and after-sales service.
Yes, we provide full customization of plate size, hole spacing, thickness and material formula to meet the design requirements of various non-standard filter tanks.
Under normal working conditions, the service life of our ABS Filter Plate can reach more than 15 years, and the integral pouring filter plate matched with it can maintain stable operation for a long time.
Yes, we have a professional technical team to provide full on-site installation guidance, debugging and acceptance support to ensure the smooth progress of your project.
Looking for a high-reliability ABS engineering plastic filter formwork for your water treatment filter tank project? Contact Lanling today to get a free customized solution, professional design consultation and full technical support for your ABS Filter Plate.
