XS
Lan ling
Product Description
XS Type Sedimentation Tank Sand Sucker (also named sedimentation tank sand suction machine) is a premium solid-liquid conveying equipment developed by Lanling, optimized with absorbed German advanced technology for wastewater treatment. This professional wastewater treatment sand sucker is specially designed for sand sedimentation tanks and aeration sand sedimentation tanks in sewage treatment plants, dedicated to lifting and transporting the mixture of settled heavy particles (sand, cinder, etc.) and sewage to the channel connected to the sand-water separator, efficiently solving the defects of traditional sand lifting equipment.
Equipped with Lanling’s proprietary submersible non-clogging sand suction pump, this equipment delivers stable sand-water mixture lifting. Compared with traditional air lift pumps, it eliminates the need for air compressors, avoiding operation noise, simplifying system structure, reducing energy consumption by over 20%, and cutting daily maintenance costs for users.
Adopting electro-hydraulic (or electric) actuator to drive the skimming rake, the structure is extremely compact. During forward travel, the rake lowers to scrape and collect dregs into the slag tank; during reverse travel, the rake lifts away from the liquid surface to prevent dregs retrograde, improving solid-liquid separation efficiency and reducing the load of subsequent treatment processes.
The equipment supports cycle automatic round-trip operation via the matched control box, realizing unattended operation. It greatly reduces labor input for sewage treatment plant operators and engineering contractors, ensuring continuous and stable operation of the sedimentation treatment link.
Parameter | Standard Specification | Customization Support |
Model | XS Series | Full customization for non-standard pools |
Adaptable Pool Width | 3-20m | Customized per pool size |
Travel Speed | 1-2m/min | Adjustable speed range |
Pump Power | 0.75-7.5kW | Matched per conveying capacity |
Power Supply | 380V/50Hz | Customizable for regional standards |
Driving Mode | Electro-hydraulic/Electric | Optional per process requirements |
Control Mode | Automatic cycle/Manual | Remote control upgrade available |
Pre-Installation Preparation
Complete rail leveling and fixing, inspect equipment integrity and component matching according to the pool design drawing.
Main Beam & Driving Device Assembly
Hoist and fix the main beam on the rail, assemble and calibrate the driving device to ensure smooth travel.
Core Component Installation
Install the submersible non-clogging pump and skimming device, adjust the height and angle of the skimming rake to meet process requirements.
Electrical System Connection
Complete wiring of the control box, limit switches and power supply, conduct insulation and safety tests.
Trial Operation & Acceptance
Conduct no-load and load test runs, verify the automatic cycle function, skimming effect and sand lifting performance.
Municipal sewage treatment plant sand sedimentation tanks and aeration sand sedimentation tanks
Industrial wastewater treatment projects (chemical, mining, food processing, etc.)
Integrated wastewater treatment equipment supporting systems
Water reclamation and reuse pretreatment sedimentation systems
Rainwater treatment and sediment separation projects
With over 20 years of R&D and manufacturing experience in wastewater treatment equipment, Lanling is a trusted supplier for global customers including engineering contractors, sewage plant operators and environmental protection integrators. Our XS Type Sedimentation Tank Sand Sucker adopts core German technology with localized optimization, strictly complies with international quality standards, supports full customization for different pool sizes and process requirements, and provides full-cycle technical support and after-sales service.
Yes, we provide full customization for pool width, pump power, travel mode and control system to match non-standard design requirements.
Our equipment has a simpler structure, no air compressor noise, lower energy consumption, and less daily maintenance, which can significantly reduce your operation cost.
Yes, the matched control box supports setting automatic operation cycles, with overload and limit protection functions, realizing stable long-term unattended operation.
Looking for a reliable sedimentation tank sand suction machine for your wastewater treatment project? Contact Lanling today to get a free customized solution, professional technical consultation and on-site installation guidance for your XS Type Sedimentation Tank Sand Sucker.
